Last update 17 Decemebr 2020
Additional information is always gratefully received, whether entirely new records (particularly historical records), or information to fill in gaps or correct errors, via the contact link under the Miscellaneous entry in the navigation bar above. Thank you.
Please select a starting letter from the links below:
Code | Signal Box | Note | ELR | Mileage | Opened | Closed | Control to |
---|
MD | Macclesfield | CMD1 | 0m 20ch | 20 March 1965 | |||
Macclesfield Central | See Macclesfield Old | ||||||
MN | Macclesfield Old | Named Macclesfield Central to 10 March 1961 then Macclesfield Station to 20 March 1965 | CMD1 | ≈0m 19ch | 16 July 1933 | 19 December 1965 last train; 1 October 1966 official |
Macclesfield (MD) |
Macclesfield Station | See Macclesfield Old | ||||||
MH | Machynlleth | SBA2 | 75m 4ch | 26 March 1960 | 19 March 2010 | Machynlleth Signalling Control Centre (MH) | |
AS | Aberystwyth control boards. Code used from 23 September 1988 | ||||||
BM | Barmouth control boards. Code used from 23 September 1988 | ||||||
DJ | Dovey Junction control boards. Code used from 23 September 1988 | ||||||
HL | Harlech control boards. Code used from 23 September 1988 | ||||||
MT | Machynlleth control boards. Code used from 23 September 1988 | ||||||
NT | Newtown control boards. Code used from 23 September 1988 | ||||||
PM | Porthmadog control boards. Code used from 23 September 1988 | ||||||
PW | Pwllheli control boards. Code used from 23 September 1988 | ||||||
TD | Talerdigg control boards. Code used from 23 September 1988 | ||||||
TW | Tywyn control boards. Code used from 23 September 1988 | ||||||
WP | Welshpool control boards. Code used from 23 September 1988 | ||||||
MH | Machynlleth Signalling Control Centre | ERTMS block markers. Opposite side of line to 1960 box | SBA2 | 75m 4ch | 19 March 2010 | ||
CP | Signals protecting Coe Pawb flat crossing with Welsh Highland Railway | ||||||
MY | Madeley | LEC4 | 149m 74ch | 1930 | 26 June 2004 last train; 28 June 2004 official delayed from 4 May 2004 |
Stoke on Trent Signalling Centre (CH) | |
MJ | Madeley Junction | Demolished on last day | WSJ2 | 156m 26ch | 19 October 1969 | 17 November 2012 | West Midlands Signalling Centre (MJ) |
Maesmawr | CAM | 10m 57ch | 1930 | 27 January 1997 | Radyr (VR) | ||
MR | Magdalen Road | 'Box moved from another (unknown) location | BGK | 90m 71ch | 1927 | ||
Maghull | SJO2 | 7m 24ch | 1875 | 10 February 1994 | Merseyrail (ML) | ||
MG | Magor | Named Magor East to 1 December 1968. Downgraded to ground frame on renaming | SWM2 | 151m 9ch | by 1884 | Newport (N) | |
DM | Down main line automatic signals | ||||||
DR | Down relief line automatic signals | ||||||
UM | Up main line automatic signals | ||||||
UR | Up relief line automatic signals | ||||||
Magor East | See Magor | ||||||
S | Maidenhead | Temporary code until control passed to Slough (S) | MLN1 | 24m 24ch | 8 December 1963 | 12 October 1974 | Slough (S) |
MW | Maidenhead West | MLN1 | 24m 60ch | May 1891 | 7 December 1963 | Maidenhead (S) | |
DM | Down main line automatic signals | ||||||
DR | Down relief line automatic signals | ||||||
UM | Up main line automatic signals | ||||||
UR | Up relief line automatic signals | ||||||
MN | Maiden Newton | WEY | 154m 12ch | 1921 | 15 May 1988 | Dorchester South (DR) | |
EBX | Maidstone East | Code used from 8 April 1962 to 1984 | SBJ | 39m 72ch | 8 April 1962 | ||
ME | Code from 1984 | ||||||
MS | Maidstone West | PWS1 | 44m 54ch | 4 June 1899 | |||
M | Maindee Main | Temporary panel | SWM2 | 157m 26ch | 16 April 1961 | 10 December 1962 | Newport (N) |
L | Maindee North | Temporary panel | HNL1 | 41m 32ch | 28 May 1961 | 10 December 1962 | Newport (N) |
MB | Maindy Bridge | Downgraded to ground frame 25 June 1966 | CAM | 2m 35ch | September 1956 | 31 July 2006 | Sidings removed |
MF | Maindy Fuel | Downgraded to ground frame 25 June 1966 | CAM | 3m 6ch | December 1933 | 19 March 1970 | Sidings removed |
Malago Vale | MLN1 | 119m 67ch | 10 April 1932 | 5 April 1970 | Bristol (B) | ||
Malden | See New Malden | ||||||
MC | Malden Crossing | Downgraded to gate box 10 November 1974 | NMS1 | 16m 67ch | 1868 | 30 January 1979 | New Malden (WM) |
Mallaig Junction | See Fort William Junction | ||||||
MC | Maltby Colliery | Named Maltby Colliery South to 7 August 1983 also had draw-ahead signals lettered A to D with no number |
BKS | 9m 31ch | 12 June 1911 | ||
M | |||||||
B | Some shunt signals at Harworth | ||||||
H | Signals at Harworth. Code used from March 1984, unclear whether separate 'box | ||||||
R | Banner repeater signals. Code used by 1987 | ||||||
X | Draw ahead signals at Harworth | ||||||
Maltby Colliery South | See Maltby Colliery | ||||||
M | Malton | Code used from 1966 | YMS | 21m 31ch | 1873 | ||
MW | Malvern Wells | WAH | 130m 13ch | 29 December 1919 | |||
M | Manchester Central | MAJ | 23 June 1935 | 4 May 1969 | Line closed | ||
AS | Manchester East Signalling Control Centre Inside same building as Manchester South |
Former Ashburys area signals | CMP2 | 182m 40ch | 19 September 2011 | ||
BS | Bredbury Sidings stop boards. Code used from 26 July 2015 | ||||||
GB | Former Guide Bridge area signals | ||||||
RJ | Former Romiley Junction area signals. Code used from 2 August 2015 | ||||||
SE | Stalybridge area signals | ||||||
LR | Manchester London Road | At Piccadilly | CMP2 | ≈188m 54ch | 28 August 1960 | On or after 15 October 1988 |
Manchester Piccadilly (MP) |
MN | Manchester North | MVE1 | 1m 61ch | 4 August 1998 | 7 April 2015 | Manchester Rail Operating Centre (MN) | |
MP | Manchester Piccadilly | CMP2 | 188m 71ch | 8 October 1988 | |||
FH | Farnworth temporary points, used from 2 May 2015 to 13 December 2015. Code not carried | ||||||
MPX | Trafford Park sidings propelling signals | ||||||
BL | Manchester Rail Operating Centre | Blackpool (North and South) line signals | HAJ | 1m 42ch | 14 July 2014 | ||
DN | Wavertree workstation signals (former Ditton signals) (planned) | ||||||
LE | Liverpool workstation signals (former Liverpool Edge Hill signals) | ||||||
LL | Liverpool workstation signals | ||||||
MC | Manchester Central area (formerly Castlefield interlocking) signals | ||||||
MN | Manchester Saltford interlocking (former Manchester North area) signals | ||||||
MP | Manchester Piccadilly area signals | ||||||
WE | Wavertree workstation signals. Code used from 2 January 2019 | ||||||
MS | Manchester South | CMP2 | 182m 40ch | 29 March 2003 | |||
VE | Manchester Victoria East | MVM MVN1 |
0m 9ch 0m 9ch |
30 March 1962 | 15 September 1998 | Manchester North (MN) | |
VW | Manchester Victoria West | MVE1 | 0m 9ch | 10 March 1929 | 8 August 1993 | Manchester Victoria East (VE) | |
M | Manea | EMP | 80m 5ch | 1883 | |||
Mangotsfield North Junction | BGL2 | 124m 45ch | 3 November 1889 | 4 January 1970 planned; 27 December 1969 actual |
|||
M | Manningham Junction | SBF | ≈207m 67ch | 1889 | 21 October 1984 | Shipley Bradford Junction (BR) | |
M | Manningtree | LTN1 | 59m 52ch | by 1910 | 28 July 1984 | Colchester [new] (CO) | |
MN | Manors | Code may have been used from 13 December 1937 | ECM7 | 13 June 1943 | Manors [temporary] (MN) | ||
MN | Manors [new] | Also known as Manors North | ECM7 | 9 February 1964 | Newcastle (N) | ||
MN | Manors [temporary] | ECM7 | 13 June 1943 | Manors [new] (MN) | |||
Manors North | See Manors [new] | ||||||
MY | Manor Yard | SDC | ≈5m 15ch | 29 June 1958 | 24 November 1985 | hand points, etc. | |
MJ | Mansfield Junction | Closure date for Mansfield South Junction, unclear whether same 'box | TSN2 | ≈124m 15ch | 15 October 1983 | Trent (TT) | |
ML | Mantle Lane | KSL | 113m 5ch | 1910 | |||
MJ | Manton Junction | GSM1 | 90m 18ch | 9 November 1913 | |||
MS | Shunt signals | ||||||
MW | Manton Wood | Code used from 1965 | MAC3 | 58m 62ch | 21 August 1977 | Worksop East (WE) | |
D | Down line automatic signals | ||||||
ME | One signal reported in 1977 notice, probably in error | ||||||
ME | March East Junction | EMP | 85m 67ch | 1885 | 21 November 1987 delayed from 31 October 1987 |
March East Junction [temporary] (ME) | |
E | Code uncertain | ||||||
ME | March East Junction [temporary] | EMP | ≈85m 68ch | 21 November 1987 delayed from 31 October 1987 |
29 November 1987 | March East Junction [reopened] (ME) | |
ME | March East Junction [reopened] | EMP | 85m 67ch | 29 November 1987 | |||
MH | Marcheys House | BWC | 1m 42ch | 1895 | |||
March North Junction | WIG | 86m 6ch | 1885 | 21 December 1975 | Whitemoor Junction (WJ) | ||
MS | March South Junction | EMP | 85m 35ch | 14 March 1928 | |||
MW | March West Junction | EMP | 86m 17ch | 1886 | 29 November 1987 | March East Junction [reopened] (ME) | |
MW | Marchwood | Upgraded from ground frame 28 November 1943 | TTF | 86m 10ch | 20 July 1925 | ||
RE | Marden | XTD | 39m 29ch | ≈1884 | 30 July 1967 | Staplehurst (SE) | |
A | Automatic signals | ||||||
Margam East | See Margam Middle | ||||||
HY | Margam Hump Yard | One source has closure on 3 December 1967 | OVE | 0m 53ch | 15 May 1949 | 1 November 1987 | Port Talbot (PT) |
MY | Code used? | ||||||
MD | Margam Middle | Named Margam East to 17 December 1950 | SWM2 | 201m 22ch | 1911 | 20 October 1963 | Port Talbot (PT) |
MM | Margam Moors | SWM2 | 199m 2ch | c July 1912 | 20 October 1963 | Port Talbot (PT) | |
GE | Margate | Named Margate A to 19 July 1959 | VIR | 73m 53ch | 1 July 1913 | 24 December 2011 | East Kent Signalling Centre (EK) |
A | Automatic signals | ||||||
Margate A | See Margate | ||||||
MB | Markham Bunker | also had draw-ahead signals lettered A to E with no number | MCB | 19 July 1970 (?) | Line closed | ||
M | Markinch Junction | Code used from 1980 | ECN2 | ≈33m 16ch | ? | 14 July 1980 | Edinburgh (ER) |
MT | Marks Tey | Code used from 3 December 1961 | LTN1 | 46m 67ch | ≈1890 | 18 October 1997 | Liverpool Street [new] (L) |
D | Down line automatic signals | ||||||
U | Up line automatic signals | ||||||
M | Marsden | MVL3 | 18m 54ch | 24 April 1993 | Huddersfield (HU) | ||
MM | Marshall Meadows | ECM7 | 68m 2ch | 25 May 1921 | 9 December 1961 | Tweedmouth (T) | |
MB | Marsh Brook | SHL | 15m 29ch | 1872 | Wales Rail Operating Centre (NS) (planned) | ||
MF | Marshfield | SWM2 | 163m 62ch | 1897? | 4 June 1966 | Cardiff (C) | |
MG | Marshgate Goods | Code probably used from 1949 | DOW | 0m 23ch | 1873 | 8 July 1979 | Doncaster (D) |
M | Marsh Junction | Code used from 26 September 1993 | MAC3 | 107m 77ch | 1908 | 30 December 2015 | York Rail Operating Centre (CB/MB) |
MJ | |||||||
Marsh Junction [Bristol] | Demolished 1993 | BRL | 0m 22ch | 2 March 1959 | 18 July 1970 | Bristol (B) | |
ML | Marsh Lane | HUL4 | 19m 58ch | 30 April 1967 | Leeds (L) | ||
ML | Marsh Lane | Downgraded to gate box 28 June 1936 | BML1 | 10m 76ch | 30 September 1906 | 23 May 1937 | Surbiton (WN) |
ML | Marsh Lane Junction | Code used by 1986 | 6 November 1988 | Bootle Junction [new] (BJ) | |||
M | Marshmoor | ECM1 | ≈15m 71ch | 4 March 1886 | 17 November 1972 | Potters Bar [new] (PB) | |
R | Repeater signals | ||||||
M | Marston Moor | Downgraded to gate box 4 June 1972: line controlled by Hammerton (H) | HAY1 | 6m 7ch | 1910 | ||
MV | Marston Vale [Ridgmont] | BBM | 6m 60ch | 6 September 2004 | |||
MM | Martin Mill | BME2 | 95m 5ch | 7 October 1934 | 12 April 1998 | Deal (EBZ) | |
MP | Maryhill Park Junction | Burnt down 14 October 1980, replacement 'box built 1984 but never opened | MRL1 | 4m 40ch | 20 October 1874 | 19 October 1980 | Yoker (YS) |
M | Marylebone | Downgraded to shunt frame 22 September 1990 | MCJ1 | 205m 52ch | 9 October 1967 | 1991 | Marylebone [new] (ME) |
ME | Reported, possibly not carried | ||||||
D | Down direction automatic signals | ||||||
U | Up direction automatic signals | ||||||
ME | Marylebone [new] | MCJ1 | 205m 77ch | 23 April 1990 | |||
OB | Oxford to Bletchley section. Code used from 2016 | ||||||
MS | Maryport Station | Believed code not carried | CBC3 | 0m 21ch | 1933 | ||
A | Draw ahead signals. Codes used from 27 January 1980 | ||||||
B | |||||||
C | |||||||
D | |||||||
M | Masborough Station North Junction | Code used from 1965 | TJC3 | 162m 10ch | 29 July 1979 | Sheffield (S) | |
MN | |||||||
MS | Masborough Station South Junction | Code used from 1965 | TJC3 | 163m 68ch | 29 July 1979 | Sheffield (S) | |
MA | Mauchline | Code used 2002 to 2003. Named Mauchline No 1 to 3 May 1970 | GSW | 43m 2ch | 1874 | ||
MM | Code from 2003 | ||||||
Mauchline No 1 | See Mauchline | ||||||
MF | Maud Foster | Downgraded to gate box 12 April 1981: line controlled by Boston West Street Junction (WS) | GRS3 | 108m 66ch | October 1877 | 30 June 1985 | Grand Sluice (GS) |
M | Meadowhall | SMC | 3m 20ch? | 10 April 1983 | Shepcote Lane Junction (SL) | ||
MD | Meaford Crossing | CMD2 | 27m 17ch | 1880 | 25 May 2002 | Stoke on Trent Signalling Centre (SOT) | |
M | Medge Hall | Downgraded to gate box 15 October 1972: line controlled by Doncaster (D). Believed code not carried | DOW | 13m 3ch | 1886 | ||
G | Meldon Quarry [train loading equipment control panel] | Draw ahead signals. Code used from 14 July 1980 | DAC | ≈199m 6ch | Quarry closed | ||
B | Melkridge Opencast Disposal Point | NEC2 | ≈37m 37ch | ||||
M | Mellis | Both codes reported in signalling notices: MS looks more likely to have been carried | LTN1 | 91m 40ch | 1883 | 14 June 1986 | Colchester [new] (CO) |
MS | |||||||
R | Melmerby South | Repeater signals | LEN1 | Line closed | |||
ML | Melton Lane | Code used from 27 July 1980 | HUL1 | 8m 41ch | 1921 | 23 November 2018 last train; 26 November 2018 official delayed from 3 April 2018 |
York Rail Operating Centre (GH) |
M | Some signals | ||||||
MM | Melton Station | GSM2 | 105m 27ch | 1942 | |||
R | Repeater signals | ||||||
R1 | Off indicators | ||||||
R2 | |||||||
X | Draw ahead signals | ||||||
EO | Meopham | VIR | 26m 0ch | ≈1876 | 27 November 1965 | Rochester (ER) | |
MN | Merllyn Level Crossing Ground Frame | DJP | 124m 28ch | Machynlleth (MH) | |||
ML | Merseyrail | HXS2 | 35m 0ch | February 1994 | |||
Metheringham | See Blankney | ||||||
M | Methley Junction | MEW2 TJC3 |
1m 12ch 187m 37ch |
1891 | 20 September 1997 | Castleford (CD) | |
MJ | |||||||
B | Metropolitan Junction | XTD | 1m 39ch | 25 November 1900 | 15 April 1976 | London Bridge (L) | |
M | Mexborough | Named Mexborough No 2 to 26 July 1970. Code used from renaming | PED5 | 15m 65ch | 1931 | 3 August 1980 | Sheffield (S) |
M2 | Code used from 1966 to 26 July 1970 | ||||||
M1 | Mexborough No 1 | Code used from 1965 | PED4 | 15m 41ch | 18 February 1900 | 13 December 1965 | Mexborough No 2 (M2) |
Mexborough No 2 | See Mexborough | ||||||
M3 | Mexborough No 3 | Code used from 1966 | WME | 9m 73ch | ≈1920 | 26 July 1970 | Mexborough (M) |
MW | Mexborough West | Code used from 1965 | PED4 | 14m 72ch | 1925 | 7 July 1965 | Mexborough No 3 (M3) |
M | Micklefield | HUL4 | ≈10m 63ch | Peckfield (P) | |||
MT | Mickle Trafford | CDM2 CHW1 |
35m 35ch 2m 59ch |
1969 | |||
ML | Code on signalling plan, believed never carried | ||||||
MJ | Midcalder Junction | Code used from 1981 | ECA2 | 89m 63ch | 1969 | 23 November 1981 | Edinburgh (EJ) |
M | Middlesbrough | Named Middlesbrough West to September 1977. Code used from renaming | DSN2 | 14m 71ch | 1877 | ||
MW | Code used to September 1977 | ||||||
R | Middlesbrough West distant signals | ||||||
ME | Middlesbrough East | DSN2 | 9 November 1969 | Middlesbrough (M) | |||
Middlesbrough West | See Middlesbrough | ||||||
MS | Middle Sidings Ground Frame | MLN1 | 10 September 1966 | Old Oak Common (OO) | |||
M | Middlestown Junction | Near Healey Mills | Route closed? | ||||
MH | Midge Hall | FCO | 22m 79ch | 5 November 1972 | |||
ME | Mile End | LTN1 | 30 January 1949 | 13 October 1968 | Liverpool Street (L) | ||
DE | Down electric line automatic signals | ||||||
DM | Down main line automatic signals | ||||||
UE | Up electric line automatic signals | ||||||
UM | Up main line automatic signals | ||||||
MG | Miles Platting Station Junction | Unclear whether code applied to this 'box or another | MVM | 1m 30ch | 1890 | 15 September 1998 | Manchester North (MN) |
M | Milford | Named Milford South to 11 September 1971 (but still referred to as such 20 May 1973) | NOC | 14m 71ch | 1957 | ||
MS | |||||||
MB | Milford & Brockton | LEC3 | 3 February 1935? | 19 May 1962 | Stafford No 4 (SD4) | ||
Milford South | See Milford | ||||||
WFM | Milford [Surrey] | WPH1 | 36m 24ch | ≈1876 | 9 December 1973 | Farncombe (WZ) | |
S | Milford West Sidings Shunters Cabin | 1 June 1980 | |||||
MK | Millbrook [Beds] | Believed code not carried | BBM | 10m 2ch | ≈1870 | 23 July 2004 last train; 6 September 2004 official |
Marston Vale (MV) |
MC | Millbrook Church Lane | Unclear whether details are correct, it is known that MC signals were used near Millbrook | BML1 | Eastleigh [new] (E) | |||
Millbrook Dock Gates | MIS | 80m 32ch | 2 June 1935 | Line closed? | |||
MB | Millbrook [Hants] | BML1 | 80m 19ch | 2 June 1935 | 8 November 1981 | Eastleigh [new] (E) | |
M | Millerhill | Code used from 1962 | NDE1 | 6m 4ch | 1873 | 6 May 1962 | Millerhill [panel] (M) |
M | Millerhill [panel] | NDE1 | 5m 42ch | 6 May 1962 | 11 December 1988 | Millerhill [new] (M) | |
M | Millerhill [new] | NDE1 | 5m 2ch | 11 December 1988 | 25 November 2012 | Edinburgh (EM) | |
MW | Waverley route signals. Code seen on proposal plans, never used | ||||||
MD | Millerhill Depot | NDE1 | ≈5m 7ch | 12 November 2017 | |||
H | Millerhill Down [Hump] Yard Control Tower | NDE1 | ≈5m 5ch | 8 April 1963 | 8 April 1981 | ||
H | Millerhill Up [Hump] Yard Control Tower | NDE1 | 16 June 1962 | 1969 | Yard closed | ||
MG | Mill Green | SPD1 | 44m 73ch | 6 March 1882 | 11 August 2014 delayed from 3 March 2014 |
Lincoln Control Centre (WS) | |
M | Millhouses & Eccleshall | TJC1 | 20 January 1973 | Sheffield (S) | |||
M | Mill Lane Junction | MRB | 39m 79ch | 1884 | 20 October 2018 last train; 23 October 2018 official |
York Rail Operating Centre (HB/MM) | |
ML | Last signal before York [IECC] (L) signals. Unclear whether this signal is jointly controlled | ||||||
MR | Banner repeater signals. Both codes shown on same diagram | ||||||
RM | |||||||
MM | Millom | CBC1 | 45m 7ch | 1917 | |||
Milner Royd | See Milner Royd Junction | ||||||
MR | Milner Royd Junction | Also known as Milner Royd | MVN2 | 29m 22ch | 1878 | 20 October 2018 last train; 23 October 2018 official |
York Rail Operating Centre (MM) |
M | Unclear whether code carried | ||||||
M | Milngavie | Code used from 1959 | MGE | 9m 8ch | 21 January 1900 | 21 October 1990 | Yoker (YH) |
Milngavie Junction | See Westerton | ||||||
MJ | Milton Junction | SCQ2 | ≈0m 5ch | 1880 | 20 May 1987 | Stoke on Trent [panel] (SE) | |
M | Milton Village | Gate box: line controlled by Brampton Fell (BF) | NEC2 | 48m 60ch | 1893 | ||
MX | Minety | Gate box: line controlled by Swindon (SN) | SWM1 | 86m 73ch | (16 June)? 1968 | 4 August 2014 last train; 23 August 2014 official |
Thames Valley Signalling Centre (SW) |
EBE | Minster | ACR | 81m 74ch | 23 June 1929 | |||
A | Automatic signals | ||||||
M | Mirfield | Named Mirfield Junction No 3 to 2 May 1970. Code used from renaming | MVN2 | 38m 49ch | ? | 18 October 1970 | Healey Mills (HM) |
M3 | Code used when named Mirfield Junction No 3, probably carried from 1963 | ||||||
D | Down line automatic signals when named Mirfield Junction No 3 | ||||||
M1 | Mirfield Junction No 1 | Code presumed, probably not carried | MVN2 | 38m 7ch | ? | 2 May 1970 | Healey Mills (HM) |
M2 | Mirfield Junction No 2 | Code referenced in signalling notice, probably not carried | MVN2 | 38m 21ch | ? | 2 May 1970 | Healey Mills (HM) |
Mirfield Junction No 3 | See Mirfield | ||||||
M4 | Mirfield Junction No 4 | Code presumed, probably not carried | ? | May 1970? | Healey Mills (HM) | ||
M5 | Mirfield Junction No 5 | Code referenced in signalling notice, probably not carried | MVN2 | ≈39m 30ch | ? | May 1970? | Healey Mills (HM) |
MI | Mistley | MAH | 61m 17ch | ≈1882 | 29 September 1985 | Colchester [new] (CO) | |
MJ | Mitcham Junction | Code used from 1969 | CMJ | 3m 9ch | 20 May 1928 | 23 May 1982 | Victoria Signalling Centre (VC) |
RC | Code used to 1969 | ||||||
CA | Automatic signals | ||||||
MM | Mitchells Main | PED3 | 10m 12ch | 1875 | 17 November 1985 | line closed | |
MB | Mitre Bridge Junction | WLL | ≈5m 70ch | 14 October 1990 | Willesden PSB (WN) | ||
MY | Mobberley | CDM2 | 11m 75ch | 1886 | |||
MW | Moira West Junction | KSL | 120m 67ch | 14 June 1896 | 23 November 1986 | Moira West Junction [temporary] (MW) | |
MW | Moira West Junction [temporary] | KSL | 120m 67ch | 23 November 1986 | 16 December 1986 | Moira West Junction [reopened] (MW) | |
MW | Moira West Junction [reopened] | KSL | 120m 67ch | 16 December 1986 | |||
MJ | Mold Junction | Possibly replaced by new 'box in 1946. Named Mold Junction No 1 to 26 February 1978 | CNH3 | 182m 29ch | 1902 | early on 23 January 2005 | Chester PSB (CR) |
Mold Junction No 1 | See Mold Junction | ||||||
MN | Monkseaton | TMB | 7m 71ch | 10 September 1979 | Line transferred to Metro | ||
D | Down direction automatic signals | ||||||
U | Up direction automatic signals | ||||||
MS | Monks Siding | SDJ2 | 11m 71ch | 1875 | |||
MK | Monktonhall Junction | ECM8 | 6m 6ch | 15 December 1912 | 1 August 1977 | Edinburgh (EM) | |
MW | Monkwearmouth | Code used from 1965. Out of use by 1997 | LEN3 | 90m 26ch | ≈1876 | 11 January 2002 | Tyneside (T) |
MN | Montrose North | Code used from 2002 | ECN4 | 30m 69ch | 1 March 1881 | ||
MS | Montrose South | Code used from 2002 | ECN4 | 30m 37ch | 1 March 1881 | 2 February 2010 delayed from 28 January 2008 |
Montrose North (MN) |
M | Moorhouse Junction | DOL1 | 163m 26ch | 3 August 1907 | 21 November 1970 | South Kirkby Junction (SK) | |
M | Moorthorpe | Named Moorthorpe South to ≈22 April 1984 | SMJ2 | 11m 63ch | 1908 | 31 May 2011 | York [IECC] (L) |
MS | Code when named Moorthorpe South | ||||||
U | Up direction distant signals | ||||||
FC | Frickley Colliery signals | ||||||
Moorthorpe South | See Moorthorpe | ||||||
Moortown | NOB3 | 19m 34ch | July 1890 | 15 April 1989 | Holton le Moor (H) | ||
ME | Morecambe | Named Morecambe Promenade to 16 November 1967 | MSM | 2m 10ch | 1907 | 6 March 1994 | Bare Lane (BL) |
Morecambe Promenade | See Morecambe | ||||||
Moreton | CWK3 | 6m 23ch | 1932 | 18 September 1994 | Merseyrail (ML) | ||
MC | Moreton Cutting | MLN1 | 51m 38ch | 1907 | 17 May 1965 | Reading (R) | |
M | Moreton Cutting Ground Frames | Unclear whether code used | MLN1 | Swindon B (SB) | |||
MM | Moreton In Marsh | OWW | 91m 56ch | 1883 | |||
M | Unclear whether code used | ||||||
ML | Moreton On Lugg | SHL | 46m 65ch | 24 October 1943 | Wales Rail Operating Centre (NS) (planned) | ||
M | Code shown in 1991 notice | ||||||
ML | Morlais Junction | LLA | 3m 57ch | 1913 | 7 July 1973 | Port Talbot (PT) | |
Morley | See Morley Low | ||||||
M | Morley Low | "Morley" carried on 'box | MDL1 | 38m 26ch | 1960? | 10 August 1985 | Batley (B) |
ML | Code used by 1980 | ||||||
RM | Banner repeater signals | ||||||
U | Up line automatic signals | ||||||
M | Morningside Road | SUB2 | 2m 7ch | 31 October 1884 | 26 June 1977 | Edinburgh (ES) | |
M | Morpeth | Code used by 1963 | ECM7 | 21 October 1978 | Morpeth [new] (M) | ||
D | Down line automatic signals | ||||||
GF | Ground frame controlled signals | ||||||
R | Repeater signals | ||||||
RU | Repeater to up line automatic signals | ||||||
U | Up line automatic signals | ||||||
M | Morpeth [new] | ECM7 | 16m 63ch | 21 October 1978 | 23 February 1991 | Morpeth [temporary] (M) | |
M | Morpeth [temporary] | ECM7 | 16m 63ch | 23 February 1991 | 14 July 1991 | Morpeth [reopened] (M) | |
M | Morpeth [reopened] | "New" 'box, reopened after refitting | ECM7 | 16m 63ch | 14 July 1991 | ||
WBQ | Mortlake | Downgraded to gate box 2 June 1974 | RDG1 | 8m 15ch | by 1892 | 19 December 1976 | Barnes (WBO) |
M | Moss | Downgraded to gate box 22 March 1970: up line controlled by Shaftholme (SH), down line controlled by Brayton (BN) | ECM2 | 163m 2ch | 1873 | 18 April 2015 | Doncaster (D) |
Mossend EWS Shunters | SCM2 | 91m 60ch | 8 May 2003 | ||||
Mossend Junction | See Mossend No 4 | ||||||
MD | Mossend No 4 | Named Mossend Junction, then named Mossend West to 26 October 1902. Code used from 1973 | EGS1 | 3m 3ch | 13 December 1892 | 4 September 1973 delayed from 12 August 1973 |
Motherwell (M) |
Mossend West | See Mossend No 4 | ||||||
MN | Mostyn | Named Mostyn No 1 to 1943. Used only as required from 10 November 2008 | CNH3 | 199m 12ch | July 1902 | 8 January 2017 last train; 9 January 2017 official |
Talacre (TE) |
Mostyn No 1 | See Mostyn | ||||||
M | Motherwell | Motherwell interlocking | WCM2 | 88m 78ch | 17 December 1972 | 26 December 2019 | West Of Scotland Signalling Centre (GMC) |
MB | Burnhouse interlocking. Code used from 6 May 2003 | ||||||
MC | Carstairs (and south) interlockings | ||||||
MG | Gartsherrie interlocking. Code used from 1999 | ||||||
MH | Haughhead interlocking. Code used from 4 July 2005 | ||||||
MR | Banner repeater signals | ||||||
MS | Mossend South interlocking. Code used from 6 May 2003 | ||||||
MY | Mossend Yard interlocking. Code used from 6 May 2003 | ||||||
R | Banner repeater signals | ||||||
MC | Motherwell Colliery | Downgraded to gate box 17 December 1972 | WCM2 | 89m 78ch | 1 November 1893 | 10 June 1984 | Motherwell (M) |
M | Unclear whether code carried | ||||||
WT | Motspur Park | Named Blue House Crossing to 23 September 1929. Code used from 27 February 1966 | RPE | 9m 52ch | 1900 | 22 July 1990 | Wimbledon (W) |
WA | Automatic signals | ||||||
EBM | Mottingham | Named Eltham to 1 October 1927 | HDR | 11 June 1894 | 14 September 1969 | London Bridge (L) | |
M2 | Mottram | Also known as Mottram Yard No 2. Named Mottram No 2 to 15 October 1978 | HAJ | 11m 32ch | 31 March 1935 | 4 April 1982 | Dinting (DG) |
M1 | Mottram No 1 | Also known as Mottram Yard No 1 | HAJ | 10m 23ch | 2 June 1935 | 14 October 1978 | Mottram No 2 (M2) |
Mottram No 2 | See Mottram | ||||||
Mottram Yard No 1 | See Mottram No 1 | ||||||
Mottram Yard No 2 | See Mottram | ||||||
MH | Mouldsworth | CDM2 | 31m 5ch | 17 June 1894 | 22 May 2006 | Mickle Trafford (MT) | |
MF | Mountfield Siding | Ground frame: line controlled by Robertsbridge (RB) | TTH | 51m 78ch | 16 March 1975 | ||
MG | Mount Gould Junction | SUT1 | 244m 39ch | 1891 | 10 November 1973 | Plymouth (P) | |
MT | Mount Pleasant Crossing | BML1 | 77m 64ch | 4 May 1902 | 11 October 1981 | Eastleigh [new] (E) | |
MC | Mow Cop | CMD1 | 11m 30ch | by 1879 | 15 May 2002 last train; 27 May 2002 official |
Stoke on Trent Signalling Centre (SOT) | |
M | Mucking Crossing | Downgraded to gate box 19 August 1973: line controlled by Low Street (L) | TLL | ≈26m 40ch | Upminster [new] (UR) | ||
M | Muckingford | Downgraded to gate box 19 August 1973: line controlled by Low Street (L) | TLL | ≈26m 13ch | Upminster [new] (UR) | ||
ME | Muirend | Code used from 1961. Open only as required from 23 July 1961 | NNH | 101m 48ch | 26 April 1903 | 16 November 1980 | Cathcart (C) |
MJ | Muirhouse Junction | Code used from 7 August 1961. Some automatic signals known with A, B or C suffix | CTC | 5m 19ch | 7 August 1961 | 18 September 1973 | Glasgow Central (G) |
D | Murrow West | Down direction automatic signals | MSG3 | 31m 1ch | 1881 | 9 October 1941 | Murrow West [temporary] (MW) |
MW | Murrow West [new] | MSG3 | 31m 1ch | 26 November 1950 | 27 November 1982 | Line closed | |
MW | Murrow West [temporary] | Named Murrow to 27 September 1948 | MSG3 | 31m 1ch | 4 November 1941 | 26 November 1950 | Murrow West [new] (MW) |
B | Murton Colliery | HEM? | Sidings closed | ||||
C |
