logoSignal box prefix codes

A (hopefully) comprehensive listing

'Boxes beginning L

Last update 5 June 2019

Additional information is always gratefully received, whether entirely new records (particularly historical records), or information to fill in gaps or correct errors, via the contact link under the Miscellaneous entry in the navigation bar above.  Thank you.

Please select a starting letter from the links below:

Introduction | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z | Non-National Rail | Ireland | Western region MAS dates | Mechanical signalling bell codes

Code Signal Box Note ELR Mileage Opened Closed Control to
BSC Lackenby No 2 Grid   DSN2   ?
LG Ladbroke Grove   MLN1 1m 65ch 1927 18 September 1967 Old Oak Common [new panel] (OO)
  Lady Anne Crossing See Batley
L Ladybank Junction Named Ladybank North to 13 February 1966 ECN2 38m 67ch 22 September 1888 12 October 1980 Edinburgh (EB)
EB Temporary code until area taken over by Edinburgh
  Ladybank North See Ladybank Junction
L Ladyburn   GOU2 121m 74ch 26 August 1900 11 June 1967 Paisley (P)
LA Laindon   FSS2 22m 68ch   4 June 1995 Upminster [new] (UR)
D Down direction automatic signals
DE At least one down direction controlled signal set within several automatic signals
U Up direction automatic signals
L Laira Junction   MLN1 244m 2ch May 1903 10 November 1973 Plymouth (P)
LE Laisterdyke East Downgraded to ground frame 11 July 1970.  Code used from 6 July 1969 LBE2 190m 24ch 1892 11 December 1970 Hammerton Street (HS)
D Down line automatic signals.  Code used by 1966
U Up line automatic signals.  Code used by 1966 LBE1 6m 49ch
L Lakenheath   ETN 82m 49ch 1883 20 August 2012
(delayed from 25 June 2012)
Cambridge (EN)
LH Code used by 1980
LR Lancaster No 1   CGJ7       Preston (PN)
CCD Lancing Code used to 14 May 1988 BLI1 8m 15ch 15 June 1963
LG Code used from 14 May 1988 when new panel installed
LS Landor Street   DBP3 40m 64ch   23 August 1969 Saltley (SY)
  Lane Head Gate box: line controlled by Low Row (LR) NEC2 45m 38ch ?
LM Langham Junction   GSM2 95m 5ch 27 October 1890
L Langley   ECM1 27m 4ch 24 May 1917 29 February 1976 Hitchin (HT)
LG Langley Green Named Langley Green Middle to 29 April 1979 GSJ2 134m 46ch October 1904 11 August 1990 Stourbridge Junction (SJ)
  Langley Green Middle See Langley Green
L Langside Junction Code possibly not carried on signals GBA 0m 61ch 27 May 1917 7 August 1973 Glasgow Central (G)
LFS2 0m 61ch
LCS Langwith Colliery Sidings also had signal LCSZ, with no number      28 April 1946? 16 February 1975 ?
L Langworth   NOB3 35m 29ch 1890
LJ Lansdown Junction This 'box may have closed and reopened, as it is also reported as closing on 23 November 1968 BAG2 86m 73ch 26 July 1942 12 November 1977 Gloucester (G)
UM Up main line automatic signals
LH Lapworth Also known as Lapworth Station DCL 116m 36ch 10 July 1932 30 August 1969 Saltley (SY)
LS Code used from 13 October 1957
  Lapworth Station See Lapworth
LJ Larbert Junction Code used from 2001 SCM3 109m 41ch 1871 12 May 2007 (last train);
14 May 2007 (official)
(delayed from 26 September 2006)
Larbert North (LN)
LN Larbert North Code used from 2002 SCM3 110m 30ch 19 October 1892 27 December 2017 Edinburgh (ECL)
  Larbert South   SCM3 110m 18ch 24 January 1892 25 February 1973 Larbert North (LN)
LN Largin   MLN3 270m 1ch 24 Januaary 1906 9 December 1991 Lostwithiel (LL)
L Larkfield Junction   WCM2 100m 78ch 22 March 1908 25 February 1973 Glasgow Central (G)
LJ Latchmere Junction   CKL 2m 64ch 6 March 1904 24 April 1983 Victoria Signalling Centre (VC)
LK Laurencekirk Code used from 2002 ECN5 210m 62ch 28 December 1910
  Lawrence Hill   BSW 1m 6ch 1890 22 March 1970 Bristol (B)
LE Leagrave   SPC1 32m 55ch   31 May 1980 West Hampstead (WH)
RLE Banner repeater signals
LN Leamington North Named Leamington Spa North to 10 July 1966 DCL 106m 24ch 7 August 1910 8 September 1985 Leamington Spa (LN)
LN Leamington Spa Original code DCL 106m 14ch 8 September 1985 8 August 2016 West Midlands Signalling Centre (LN/OL)
OL Oxford to Leamington section.  Code used from 4 May 2004
  Leamington Spa North See Leamington North
  Leasowe   CWK3 5m 61ch 1938 21 August 1994 Merseyrail (ML)
CBH Leatherhead Named Leatherhead South to 10 July 1927 BTH3 17m 74ch 1902 5 August 1990 Wimbledon (W)
CA Automatic signals
D Distant signals
  Leatherhead South See Leatherhead
  Lebberston Road Gate box: line controlled by Seamer West (SW) HBS 46m 72ch ?
LJ Leckwith Junction   SWM2 171m 49ch 29 November 1931 27 March 1966 Cardiff (C)
L Ledbury   WAH 136m 6ch 1885
LD Reported, but unclear if carried on signals
L Leeds   HUL4 20m 47ch 1 May 1967 19 August 2001 (in part);
16 June 2002 (remainder)
York [IECC] (L)
D Down line automatic signals
DV Down viaduct line automatic signals
E Signal at Wintersett
(may be a grafittied "L" plate)
R Repeater signals
RL Some banner repeater signals
RU Banner repeater to up line automatic signals
U Up line automatic signals
UV Up viaduct line automatic signals
WST Notice board at Wintersett
LJ Leeds City Junction   DOL2 c185m 44ch   by 30 April 1967 Leeds (L)
E Leeds East Code used from June 1936 HUL4 20m 29ch 18xx (shortened 1936) 30 April 1967 Leeds (L)
P Leeds Parcels Concentration Depot Shunt signals     by 1 May 1967   Depot closed, area rebuilt and reopened as Leeds station, platforms 1-6 controlled by York [IECC] (L)
PD
W Leeds West   DOL2 185m 60ch 5 April 1937 30 April 1967 Leeds (L)
  Leek Brook Junction Disused since 8 February 1989 SCQ2 6m 58ch 1872 21 August 1993 Line closed
CVL 17m 50ch
LR Leicester Code used from 1987 SPC5 99m 30ch 29 June 1986 2 January 2012 East Midlands Control Centre (LR)
LRR Banner repeater signals
X "Creep" signals at Kettering
LN Leicester North   SPC5   14 May 1911 29 June 1986 Leicester (LR)
  Leigh   NSS 10m 24ch by 1879 11 July 1999 Caverswall (CL)
LE Leigh-on-Sea   FSS2 32m 30ch   9 July 1995 Upminster [new] (UR)
LN Leighton Buzzard No 1   LEC1 c40m 5ch     Bletchley (BY)
L Leighton Buzzard No 2   LEC1 c40m 22ch   3 July 1965? Bletchley (BY)
L Leith Docks   LHS1 0m 53ch 1 August 1903?   Edinburgh (EP)
EBC Lenham Code used from opening SBJ 49m 7ch 23 July 1961 28 April 1984 Maidstone East (ME)
LS Lenton South Junction   TSN1 c125m 30ch     Trent (TT)
LE Lenzie   EGM 6m 23ch March 1914 13 December 1971 Greenhill Junction (GJ)
LE Leominster Named Leominster South End to 16 October 1966 SHL 38m 60ch 1875   Wales Rail Operating Centre (NS) (planned)
  Leominster South End See Leominster
L Lesmahagow Junction   WCM2 89m 49ch 2 February 1913 17 December 1972 Motherwell (M)
LE Letchworth   SBR 34m 43ch 16 June 1907 22 November 1975 Hitchin (HT)
LE Leuchars   ECN2 50m 79ch 12 September 1920
L Lewden Crossing   PED2 7m 18ch by 1904 20 July 1981 Barnsley (BY)
  Lever Brothers Sidings See Port Sunlight Sidings
LW Lewes   KJE1 50m 3ch 1888
(delayed from 27 February 2015 and again from 11 March 2019)
Three Bridges Rail Operating Centre (TLW) (planned)
  Ley Crossing Gate box: line controlled by Gloucester (G) SWM2 120m 20ch   14 May 2012 Gloucester (G)
LC Lichfield City Named Lichfield City No 1 to c25 November 1973 BJW3 16m 61ch   12 October 1992 Aston (AN)
  Lichfield City No 1 See Lichfield City
TV Lichfield Trent Valley Junction   BJW3 18m 13ch 1897
LD Lichfield Trent Valley Low Level   LEC2 116m 23ch 1911 27 May 2008 Rugby Signalling Control Centre (LS/NL)
LDR Banner repeater signals
LN Code used from 11 December 2007
LN Lidlington Believed code not carried BBM 8m 49ch   6 September 2004 Marston Vale (MV)
L Lightmoor Junction   MJI1 160m 15ch 1951 23 October 2006 Madeley Junction (MJ)
LK Lime Kiln Crossing Named Lime Kiln Sidings to 25 February 1994.  Code used by 1969.  Downgraded to Gate Box 14 December 1997; mostly out of use since then. WVL 6m 14ch 1887 30 November 2007
(demolished 20 June 2007)
Park Junction (PJ)
DM Down main line automatic signals
UM Up main line automatic signals
  Lime Kiln Sidings See Lime Kiln Crossing
LH Limestone Hall Gate box: line controlled by Silecroft (ST) CBC1 47m 44ch
  Limpley Stoke Out of use for long time before closure BFB 4m 24ch 25 April 1910 24 August 1969 Bathampton Junction (BH)
BL Lincoln Control Centre Barnetby to Lincoln section SPD3 83m 30ch 1 September 2008
LG Lincoln to Gainsborough section
NL Newark to Lincoln section
SL Spalding to Lincoln section
WS Werrington Junction to Sleaford Junction section
HS Lincoln High Street   SPD3 82m 49ch 1874 31 August 2008 Lincoln Control Centre (LG)
  Lincoln Road [Enfield] Downgraded to gate box 26 November 2001: line controlled by Liverpool Street [new] (L) ENT 10m 25ch ?
LR Lincoln Road [Retford]   ECM1 133m 4ch 21 August 1938 24 October 1976 Retford (RD)
LS Lincoln Street Crossing   RAC 127m 60ch 1916 29 September 2001 Trent (TT)
CT Lindsey Oil Terminal Control Tower     c103m 53ch by 26 October 1967
- Lingfield   HGG1 26m 15ch 10 March 1884 11 July 1987 Oxted [new] (OD)
  Lingwood Downgraded to gate box 10 May 1967: line controlled by Brundall Junction (BL) NAY 8m 2ch 1882
D Linlithgow Down direction automatic signals EGM1 29m 54ch c.1897 10 February 1979 Edinburgh (EL)
LP Lipson Junction   MLN1 244m 29ch February 1891 26 November 1960 Plymouth (P)
LD Liskeard Junction   MLN3 264m 66ch 3 June 1915
RW Liss   WPH1 51m 40ch 1878 16 February 1975 Petersfield (PF)
  Little Barford CEGB   ECM1 49m 69ch   ? Peterborough (P)
PN Littleborough Temporary block post MVN2 c14m 40ch 9 February 1985 19 August 1985 Preston (PN)/
Smithy Bridge (SB)
SB
LB Little Bytham   ECM1 92m 27ch 1 December 1912 5 July 1975 Peterborough (P)
D Down direction automatic signals
U Up direction automatic signals
L Littlefield Believed code not carried MAC3 108m 73ch 1884 26 September 1993 Pasture Street (P)
LH Littlehampton   BLI2 61m 69ch 1886
LHY Littlehampton depot sidings
CA Automatic signals
LH Littlehaven Downgraded to gate box 1986: line controlled by Horsham (CBP) TBH1 36m 49ch 13 March 1938 15 October 2012 Three Bridges [new] (T)
LT Unclear whether code used
L1 Little Ilford No 1   FSS2 6m 47ch ? ?
FRL1 Fog repeater signals
L2 Little Ilford No 2   FSS2 6m 69ch ? 10 April 1961 Barking (BK)
FRL2 Fog repeater signals
LM Little Mill Code used from September 1961 ECM7 c39m 33ch   15 April 1978 Alnmouth (A)
D Down line automatic signals
U Up line automatic signals
LM Little Mill Junction   HNL1 30m 52ch 1883   Wales Rail Operating Centre (NS) (planned)
DH Down Hereford line automatic signals
UH Up Hereford line automatic signals
L Littleport   BGK 75m 76ch 1882
  Little Steeping   GRS3 120m 20ch June 1889 11 March 1989 Bellwater Junction (BJ)
X Littleton Colliery Draw ahead signals RBS3 22m 74ch     Wolverhampton (WN)
LCX Setback signals
LT Littleworth Code not carried on all signals WEB 87m 61ch 1875 3 November 2014
(delayed from 3 March 2014)
Lincoln Control Centre (WS)
L Unclear whether code ever used
LM Littons Mill Crossing Downgraded to gate box 9 July 2012: line controlled by Monks Siding (MS) SDJ2 11m 45ch 1890
  Liverpool Edge Hill See Edge Hill
LE1 Liverpool Exchange No 1 Code used by 1973       30 April 1977? Line closed
LS Liverpool Lime Street   WJL4 193m 37ch 25 January 1948 13 July 2018 (last train);
30 July 2018 (official)
Manchester Rail Operating Centre (LL)
L Liverpool Street   LTN1 0m 22ch 11 September 1949 24 March 1989 Liverpool Street [new] (L)
DE Down electric (through) line automatic signals
DM Down main (local) line automatic signals
DS Down suburban line automatic signals
US Up suburban line automatic signals
L Liverpool Street [new]   LTN1 0m 22ch 2 April 1989
DS Down Southend line automatic signals
R Some banner repeater signals (most used suffix R)
RMD Romford-Upminster line, Romford-bound.  Code quoted in Crossrail works document but not shown on signalling plan
UMD Romford-Upminster line, Upminster-bound.  Code quoted in Crossrail works document but not shown on signalling plan
US Up Southend line automatic signals
S North London Lines (controlled from Stratford North London Lines workstation in a separate part of the building to the Great Eastern and West Anglia workstations) 4 January 2011 Upminster [new] (NL) and Liverpool Street [new] (L)
LW Liverpool Street West   LTN1 0m 22ch 2 July 1894 25 September 1949 Liverpool Street (L)
LL Llandaff Loop Junction   CAM 4m 37ch 1900 12 May 1998 Radyr (VR)
LJ Code shown in 1966 plan
UL Up Llandaf line automatic signals
LY Llandarcy Named Lonlas South to 1 May 1923.  Downgraded to ground frame 25 February 1973 SDI2 0m 37ch December 1920
  Llandeilo Junction See Llandilo Junction
  Llandilo East Junction See Llandilo Junction
LJ Llandilo Junction Named Llandilo East Junction to 26 November 1966.  Also known as Llandeilo Junction SWM2 223m 50ch 1913 8 December 1973 Port Talbot (PT)
LE Llandre Crossing Downgraded to ground frame c1966 SBA2 89m 58ch 21 July 1911   Machynlleth (MH)
LJ Llandudno Junction   CNH3 223m 55ch 10 February 1985
CB Former Colwyn Bay signals.  Code used from 2 November 1991 to 10 November 1991
  Llandudno No 2 See Llandudno Station
LS Llandudno Station Named Llandudno No 2 to 13 September 1970.  Code not carried.  Closed 19 February 1978; reopened 19 March 1978 LLJ 3m 0ch June 1891   Wales Rail Operating Centre (planned)
LO Code shown on 2009 signalling plan
  Llanelli West Downgraded to gate box 2 February 1969: line controlled by Port Talbot (PT).  "Slots" signals 247, 286 SWM2 225m 29ch 1877
  Llanfair P G See Llanfairpwll
  Llanfairpwll Downgraded to gate box 2 December 1973: line controlled by Bangor (BR).  Name board has "Llanfair P G" CNH3 242m 22ch 1871
LR Llanidloes Road Gate box: line controlled by Machynlleth (MH) SBA2 52m 70ch ? 19 February 2011 Machynlleth (MH)
LS
LT Llanrwst Code in use by 2013 LJT1 11m 8ch 1880
LC Llanstephan Crossing Rebuilt July 1960.  Code in use by March 1972 SWM2 245m 58ch by 1885 25 March 1979 Carmarthen Junction (CJ)
LJ Llantarnam Junction   HNL1 36m 26ch November 1913 29 November 1983 Newport (N)
UH Up Hereford line automatic signals
LE Llantrisant East Downgraded to ground frame 25 April 1966 SWM2 181m 43ch 1891 c10 November 1984 Cardiff (C)
LW Llantrisant West Downgraded to ground frame 5 May 1966 SWM2 181m 76ch 1876 18 September 2011 Cardiff (C)
  Llanwern   SWM2 154m 70ch 1891 17 April 1961 East Usk (EU/U)
S Llanwern Spencer Works
C Coal hopper discharge bunker lines.  Code used from 1988
L Lockerbie Code used from 1971 WCM1 25m 58ch 18 January 1892 29 April 1973 Motherwell (MC)
LS Lockes Siding   MVN2     28 February 1982 Wakefield Kirkgate East (WE)
LL Lock Lane Crossing Downgraded to gate box 29 September 1969: line controlled by Trent (TT) SSJ1 120m 30ch January 1957 4 January 2010? East Midlands Control Centre (SS)
LW Lockwood Formerly named Lockwood No 2.  Believed code used from 9 July 1961 PEH 1m 47ch   1968 Huddersfield (HU)
  Lockwood No 2 See Lockwood
WC Loco Junction   BML1 2m 1ch 8 September 1918 16 June 1974 Queens Road [London] (WD)
  Lodge Farm Crossing Downgraded to gate box 19 January 1930 BTH3 25m 38ch 1877 1 December 1985 Holmwood (CBL)
LN Lofthouse North   DOL2 178m 44ch June 1893 28 November 1970 Wakefield Westgate North (WN)
LM Code reported in 1970 notice, probably in error
LO Lolham Downgraded to gate box 13 April 1975: line controlled by Tallington (T) ECM1 83m 32ch 10 September 1898 20 May 1975 Tallington (T)
  London Bridge See London Bridge Eastern
L London Bridge   LBW 0m 13ch 19 July 1975 23 December 2017
(in part)
Three Bridges Rail Operating Centre (TL)
(in part)
LBC 0m 13ch
XTD 2m 2ch
E London Bridge Eastern Named London Bridge to 19 July 1975 LBW 0m 20ch 17 June 1928 15 April 1976 London Bridge (L)
A Automatic signals LBC 0m 20ch
R1D Distant signals XTD 2m 9ch
R2D
LG London Gateway Port   THN ? 24 June 2013
(delayed from 2 April 2013 and 3 June 2013)

L1 London Road No 1 [Manchester]       31 October 1909 2 January 1960 Manchester London Road (LR)
LR London Road Junction   SPC4 98m 74ch   29 June 1986 Leicester (LR)
LR London Road Junction   SPC7 128m 23ch   12 July 1969 Derby (DY)
SPC8 127m 54ch
DBP 0m 0ch
LG Longannet   KNE1 5m 62ch 9 September 1969
L
S Longannet SSEB control room
L Longbeck Gate box before 1932.  Code used from 8 February 1970 DSN3 25m 32ch 1932
LE Longbridge   HND1       Line closed
  Longbridge East Downgraded to shunt frame 27 April 1997 HND1 0m 26ch 12 November 1916   Line closed
  Longbridge Shunt Frame   BAG2 49m 21ch ?   Line closed
LE Long Eaton Town Crossing   TCC c120m 52ch   18 October 1969 Trent (TT)
EN Longfield Named Fawkham to 1961 VIR 23m 22ch by 1873 28 November 1965 Farningham Road (EM)
A Automatic signals
LF Longforgan Code used from 2002 SCM5 5m 55ch 1929
OC Longhedge Junction   FLL1 1m 64ch 1890 23 July 1978 Stewarts Lane (S/SL)
LT Longhirst Downgraded to gate box 12 November 1978: line controlled by Morpeth [new] (M).  Code used from December 1962 ECM7 20m 17ch   c.2 October 1988 Morpeth [new] (M)
D Down line automatic signals
U Up line automatic signals
LH Longhoughton Code used from September 1961 ECM7 c37m 60ch     Alnmouth (A)
D Down line automatic signals
U Up line automatic signals
LL Long Lane   LEN3 46m 34ch 1873 29 November 1997 Low Gates (LG)
D Down line automatic signals
U Up line automatic signals
  Long Lane Crossing See Craven Arms
LT Longport Junction   CMD2 16m 71ch 31 December 1939 17 May 2002 (last train);
27 May 2002 (official)
Stoke on Trent Signalling Centre (SOT)
CS Longsight Carriage Maintenance Depot Depot shunt signals CMP2 ?? ??
CMN North end signals.  Code used from 12 October 1986
CMS South end signals.  Code used from 12 October 1986
LT Longsight No 1   CMP2       Manchester Piccadilly (MP)
LN Longtown Junction           Carlisle (CE)
LG Longwood Goods Believed code used from 9 July 1961 MVL3 23m 34ch   c4 March 1978 Huddersfield (HU)
L Code used at closure
  Lonlas South See Llandarcy
LL Lostwithiel   MLN3 277m 34ch 1893
LH Loughborough   SPC5 c111m 58ch 19 June 1892 11 April 1987 Leicester (LR)
U Loughborough Junction   HHH 3m 37ch c1870 29 November 1981 Victoria Signalling Centre (VS)
A Automatic signals
LM Lowdham   NOB1 7m 26ch 14 June 1896 1 October 2016 East Midlands Control Centre (NN)
LE Low Ellers Unclear if code carried BKS 15m 78ch January 1909 20 May 1979 Decoy No 1 (DY)
L Lowestoft   NOL 23m 23ch 1885   Colchester [new] (YL) (planned)
LF Low Fell   ECM5     20 April 1963 Tyne Yard (TY)
LFS Low Fell Sidings Downgraded to ground frame 20 April 1963 BLF       Tyne Yard (TY)
L Lowfield   BON 7m 13ch 3 January 1887 26 April 1987 Line closed
LJ Lowfield Junction   PED5 17m 48ch 12 July 1908 8 June 1980 Denaby Crossing (DX)
LG Low Gates   LEN3 43m 25ch 1956
LB Former Boroughbridge Road signals
U Up line automatic signals
LH Low House Crossing   SAC 299m 55ch 1900
LM Low Moor Formerly Low Moor No 2 MRB 37m 38ch   20 July 1986 Mill Lane Junction (M)
LR Low Row   NEC2 46m 24ch 1874 6 April 2009 Low Row [new]
LR Low Row [new]   NEC2 46m 19ch 6 April 2009
L Low Street   TLL 24m 11ch   8 April 1996 Upminster [new] (UR)
LR Lucker Code used from March 1961 ECM7 49m 17ch   20 August 1978 Chathill (CL)
CL Temporary code for one day until transferred to Chathill
D Down line automatic signals
U Up line automatic signals
- Luffenham Junction   PMJ c4m 10ch   11 March 1990 Manton Junction (MJ)
LU Lugton Code used from 2002.  Supposed to be permanently switched out from 4 December 2012 but cancelled GBK 13m 50ch 5 May 1929
GL Lydney Downgraded to gate box 3 March 1969: line controlled by Newport (N) and Gloucester (G) SWM2 133m 41ch 1918 29 October 2012 South Wales Control Centre (NT)
LY Lydney Junction Downgraded to ground frame 22 February 1969: line controlled by Newport (N) SWM2 133m 21ch 1904   South WalesControl Centre (NT) (planned)
WDX Lymington Junction   BML2 93m 65ch 18 July 1915 17 October 1978 Brockenhurst (BH)
RWA Distant to automatic signals
WA Automatic signals
CCS Lyminster Crossing   BLI1 18m 1ch 1877 22 January 1980 Arundel (AR)
B Lynemouth Alcan Bunker line signals
(also had draw-ahead signals lettered A to D, F, H, J with no number)
BWC 6m 12ch 1956



Introduction | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z | Non-National Rail | Ireland | Western region MAS dates | Mechanical signalling bell codes
