Engineer's Line References (ELRs)

A (hopefully) comprehensive listing

Codes beginning T

Last update 27 October 2020

Additional information is always gratefully received, whether entirely new records (particularly historical records), or information to fill in gaps or correct errors, via the contact link under the Miscellaneous entry in the navigation bar above.  Thank you.

Please select a starting letter from the links below:

Introduction | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z | Lines without codes | ELR/LOR converter | LUL system | DLR system | Canals

ELR Line name Mileages Datum Notes
TAD Trecwn Branch 0.00 - 2.40 Trecwn Junction
TAH Tottenham and Hampstead Line see separate portions
    TAH1 Junction Road Junction to South Tottenham 2.42 - 5.73 St Pancras via Kentish Town
    TAH2 South Tottenham to Woodgrange Park Junction 5.73 - 11.79 St Pancras via Kentish Town
    TAH3 Woodgrange Park Junction to Barking Station Junction 11.79 - 13.42 St Pancras via Kentish Town
    TAH4 Barking Station Junction Barking bay platform 13.12 - 13.62 St Pancras via Kentish Town
TAI Taibach Loop 1.13 - 1.37 Copper Works Junction
TAL Talywain Branch 9.46 - 13.12 George Street Junction
TAN Tannochside Branch 0.00 - 1.21 Tannochside Junction
TAT Tattenham Corner Branch 15.23 - 23.37 Charing Cross
TAZ Talywain Old Siding 13.15 - 13.33 George Street Junction via Golynos Junction (reverse) Formerly part of CFZ
TBB Tillynaught to Banff Branch 58.34 - 64.35 Aberdeen
TBC Thornley Colliery Branch 1.42 - ?? Thornley Junction off TOY
TBD Taff Bargoed Branch 13.36 - 22.77 Taff Vale Extension Junction
TBG Three Bridges Junction to Groombridge Junction Line 29.28 - 46.22 London Bridge via Redhill
TBH Three Bridges to Havant via Horsham Line see separate portions
    TBH1 Three Bridges to Arundel Junction North 29.28 - 59.74 London Bridge via Redhill
    TBH2 Arundel Junction North to Havant 19.03 - 37.25 Brighton
TBY Tenbury Branch 137.39 - 152.56 Paddington via Didcot, Charlbury and Stourport
TBZ Talywain Ballast Branch 12.12 - 12.29 George Street Junction
TCB Treeton Colliery Branch ?? - ??
TCC Trent East Junction – Clay Cross South Junction [Toton to Clay Cross Line] 119.69 - 142.10 St Pancras via Toton
TCF Tyneside Central Freight Depot 100.23 - 100.65 Leeds Wortley Junction via Harrogate Starbeck, Northallerton Low Level and Sunderland
TCJ Three Cocks Junction Line 0.00 - 0.34 Three Cocks Junction
TCV Tamworth Curve 23.34 - 23.62 Derby
TCW Taunton Concrete Works 162.57 - 163.04 Paddington via Box
TCW Temple Hirst Junction and Chaloner's Whin Junction via Selby Line see separate portions
    TCW1 Temple Hirst Junction to Selby South Junction 169.16 - 174.11 Kings Cross
    TCW2 Selby to Chaloners Whin Junction 174.75 - 186.14 Kings Cross
    TCW3 York Bar Wall 188.00 - 188.20 Kings Cross Structures only
TCY Tibshelf Colliery Branch see separate portions
    TCY1 Colliery Branches Junction to Tibshelf Colliery 138.74 - 139.72 St Pancras via Toton
    TCY2 Tibshelf to No 1 Colliery 0.00 - 0.13 Tibshelf Town Junction
TDB Tweedmouth Dock Branch ?? - ??
TDE Tilbury Docks East Side 0.00 - 1.17 Grays East Junction
TDG2 See RDG2; shown on Wokingham station footbridge in error (see photo)
TDZ Mineral Loop (Tufts Junction to Drybrook Road) 10.60 - 17.29 Berkeley Road Junction
TEI Teign Valley Railway 0.00 - 7.57 Heathfield 0.00 - 0.22 now MOB sidings
TEM Temple Branch 0.00 - 0.79 Knightswood South Junction Anniesland, North British Railway route
TEN Cambridge Chord (Stansted East Junction to North Junction) 0.00 - 0.49 Stansted North Junction
TEP Templecombe Loop 35.57 - 36.?? Bath Junction
TES Trent East Junction to Sheet Stores Junction Curve 0.00 - 0.30 Trent East Junction
TET Tetbury Branch 0.00 - 7.19 Kemble Station
TEV Teversall Branch 142.48 - 145.69 Kings Cross
TEW Tewkesbury Quay Branch 1.46 - 2.26 Tewkesbury Junction
TEY Tyne Yard 74.12 - 77.37 York
TFC Thornton Field Sidings 3.32 - 3.69 Liverpool Street
TFD Tanfield Branch 0.00 - 7.74 Redheugh Bank Foot Junction
TFH South Tottenham and Thames Haven Line see separate portions
    TFH1 South Tottenham Junction to Woodgrange Park Junction Now TAH2
    TFH2 Woodgrange Park Junction to Barking Tilbury Line Junction West Now TAH3
    TFH3 Barking Tilbury Line Junction West to Thames Haven Junction Now part of FSS2 and TLL
    TFH4 Thames Haven Junction to Thames Haven Now THN
TFK Touch Fork 17.78 - 18.32 Edinburgh Waverley
TFN Trimley to Felixstowe North Freightliner Terminal Line 0.00 - 2.13 Trimley
TFT Treforest Trading Estate Branch Now TTB
TFW Tipton Basin Branch/Tipton Five Ways 149.41 - 150.02 Paddington via Didcot and Charlbury
TFZ Treferig Branch 1.22 - 3.78 Common Branch Junction
TGN Treloggan Curve 301.49 - 301.64 Paddington via Box and Plymouth Millbay (reverse)
TGO Thurgoland Coal Branch ?? - ?? Approx 2 miles long.  Barnsley area
TGW Tradeston Gas Works Branch 0.00 - 0.22 West Street Junction West Street Depot, Glasgow
TGZ Tenby Goods Branch 0.00 - 0.34 Black Rock Junction
THA Thame Branch (WR end) 0.00 - 18.47 Princes Risborough Now includes PRT.  Distances shown are for whole branch
THB Thorncliffe Branch 166.18 - 167.12 St Pancras
THC Thurcroft Colliery Branch 3.68 - 6.32 Brancliffe East Junction
THD Toton Yard (East Side) ?? - ?? St Pancras (presumed)
THG Norwich Thorpe Goods and Carriage Sidings 0.00 - 0.32 Junction with LTN2
THH Thrushbush Branch 0.00 - 1.39 Rochsoles Branch Junction
THJ Torrington and Halwill Line 0.00 - 20.40 Torrington Formerly THL
THL Torrington and Halwill Line Now THJ
THL Toton High Level Goods Line 119.17 - 121.44 St Pancras
THM Thirsk to Malton Line 0.00 - 22.52 Sessay Wood Junction, renamed Pilmoor South Junction
THN Thames Haven Branch 26.41 - 30.44 Fenchurch Street
THO Thornbury Branch 0.00 - 7.37 Yate Main Line Junction
THR Troon Harbour Branch 33.08 - 35.18 Bridge Street Station
THT Treherbert Branch 13.03 - 24.46 Cardiff Bute Road
TIB Tivetshall to Beccles Branch 0.04 - 19.31 Tivetshall
TIR Tilbury Riverside Branch 22.06 - 22.45 Fenchurch Street
TIV Tiverton Branch 179.09 - 183.51 Paddington via Box
TJB Thornhill Junction Branch 185.44 - 186.35 St Pancras
TJC Tapton Junction (Chesterfield) to Colne see separate portions
    TJC1 Tapton Junction to Freight Terminal Junction 146.59 - 160.34 St Pancras via Leicester and Toton
    TJC2 Freight Terminal Junction to Masborough 160.34 - 163.74 St Pancras via Leicester and Toton
    TJC3 Masborough to Colne 161.77 - 232.39 St Pancras via Leicester, Toton and Barrow Hill
TJE Budleigh Salterton Branch (Tipton St Johns to Exmouth) 164.30 - 175.29 Waterloo
TJG Thorne Junction to Gilberdyke Line see separate portions
    TJG1 Thorne Junction to Thorne North Station 7.69 - 9.09 Doncaster Marshgate Junction via original route
    TJG2 Thorne North Station to Gilberdyke 0.00 - 14.06 Gilberdyke Junction
TJS Townhill Junction to Lilliehill South Junction ?? - ?? Dunfermline.  Joins CWH1 to WFB.  Approx 1m 58ch long
TJY Tavistock Junction Marshalling Yard 242.42 - 243.03 Paddington via Box
TLA Third London Airport (Stansted Airport Link) 33.54 - 36.67 Liverpool Street via Clapton
TLK Talke/Talk O' Th' Hill Branch 0.00 - 2.32 Chatterley Junction
TLL Tilbury Loop Line (Barking to Pitsea via Tilbury) 7.60 - 32.43 Fenchurch Street
TLP Tonbridge Loops (Bickley to Petts Wood) see separate portions
    TLP1 Bickley Junction to Petts Wood Junction (Fast lines) 12.38 - 13.29 Victoria
    TLP2 Bickley Junction to Petts Wood Junction (Slow lines) 12.49 - 13.35 Victoria Listed from 12.38
TMB Tynemouth Branch 0.00 - 11.35 Heaton South Junction
TMD Temple Mills Depot branch 9.381km - 13.428km St Pancras
TMG Temple Meads Goods Lines 118.19 - 118.37 Paddington via Box
TML Trans Manche Link (Continental Junction to Eurotunnel Boundary) 66.27 - 68.64 + Channel Tunnel Charing Cross via Chelsfield Network Rail/Eurotunnel boundary 67.34 (concession), 68.15 (signalling), 68.68 (maintenance)
  Note Channel Tunnel 69.28 - 100.57 portal to portal Charing Cross via Chelsfield
66.48 - 105.21 total Charing Cross via Chelsfield
5.5890 - 67.8200 km total Westenhanger (1974 scheme start point)
TMP Thorpe Marsh Power Station 163.46 - 164.37 Kings Cross via Carcroft
TNC Treeton North Junction to Catcliffe Junction Curve 0.00 - 0.25 Treeton Norh Junction
TND Tiverton and North Devon Line 0.00 - 8.41 Morebath Junction
TNL Troon Harbour Loop 0.00 - 0.64 Troon Passenger Station Troon Station to Templehill Junction on THR
TNQ Truro and Newquay Line 0.00 - 17.20 Blackwater East Junction
TNT Trent North Curve 119.70 - 120.72 St Pancras
TNW Thornton North to West Junctions Curve 0.00 - 0.70 Thornton North Junction
TNY Thornton Yard 32.16 - 33.42 Stirling
TNZ Tymaen Branch 11.36 - 11.64 R&SB Junction
TOB Tottington Branch 10.01 - 13.32 Manchester Victoria
TOC Treeton and Orgreave Colliery Branch 0.07 - 0.37 Treeton
TOL Sunniside Branch (Tow Law) 0.00 - 1.21 Tow Law Junction
TOM Thrapston to Orton Mere (Peterborough) Branch 27.58 - 47.08 Blisworth Continuation of BPH
TON Tondu North Loop 0.00 - 0.16 Tondu North Junction
TOP Topsham Quay Branch 0.00 - 0.35 Junction with EMT
TOR Torquay Branch 214.43 - 228.68 Paddington via Box
TOT Totnes Quay Branch 0.00 - 0.62 Totnes Quay Branch Junction
TOY Thornley Branch 0.00 - 1.42 Thornley Junction
TPF Trafford Park Freightliner Terminal ?? - ??
TPL Templehill Goods Branch 0.00 - 0.10 Templehill Junction
TPS Trafford Park Sidings see separate portions
    TPS1 Trafford Park Junction to Miscellaneous Sidings 0.00 - 0.58 Trafford Park West Junction??
    TPS2 Bridgewater Junction to Metropolitan Vickers Sidings 0.13 - 0.60 Trafford Park West Junction??
    TPS3 Trafford Park Junction to Trafford Park West Junction 31.66 - 32.33 Liverpool Central
TRE Treamble Branch 0.00 - 3.20 Shepherds Junction
TRI Trimsaran Branch 4.10 - 5.28 Burry Port
TRL St Pancras to Cheriton (Channel Tunnel Rail Link) see separate portions
    TRL1 St Pancras to York Way South Junction 0.000km - 1.409km St Pancras
    TRL2 York Way South Junction to Dagenham Junction 1.409km - 21.264km (mean) St Pancras
    TRL3 Dagenham Junction to Eurotunnel boundary 21.264km (mean) - 109.948 St Pancras
    TRL4 Ripple Lane chords 18.864km - 20.522km (mean) St Pancras via Dagenham Junction (reverse)
    TRL5 North Kent Line Connection Junction (Ebbsfleet) to Springhead Road Junction (CTRL portion) 35.555km - 37.477km (mean) St Pancras See also ESJ
    TRL6 Not allocated n/a n/a
    TRL7 Ashford Down East Chord ?? - 92.696km St Pancras
    TRL8 Not allocated n/a n/a
    TRL9 East Coast Main Line connection c0.790km - 1.382km St Pancras Exact limit uncertain
TRN Troon avoiding line 33.05 - 35.05 Bridge Street Station Partially included in ZZA4
TRO Trosnant Junction Line 0.00 - 0.27 Trosnant Junction (Vale Of Neath)
TRP Trentham Park Branch 0.00 - 1.14 Trentham Junction
TRV Trenance Valley Branch 0.00 - 1.53 Trenance Junction
TRW Truro and Newquay West Loop/Chacewater West Loop 0.00 - 0.18 Chacewater (Blackwater) West Junction
TRX Tarbrax Branch 0.00 - 1.70 Tarbrax Junction
TRZ Treforest Branch 12.27 - 14.01 Cadoxton Junction
TSB Tyseley South Junction to Bearley Junction Branch 0.00 - 17.69 Tyseley South Junction
TSC Tibshelf to Silverhill Colliery Branch (Tibshelf and Teversall Line) 137.43 - 146.36 St Pancras via Toton
TSE South Tottenham East Junction to Tottenham South Junction see separate portions
    TSE1 South Tottenham East Junction to Tottenham West Junction 5.73 - 6.22 St Pancras via Kentish Town
    TSE2 Tottenham South Junction to Tottenham West Junction 5.41 - 5.54 Liverpool Street
TSJ Twickenham Junction to Shacklegate Junction Line 11.49 - 12.53 Waterloo
TSN Trent South to Nottingham Line see separate portions
    TSN1 Trent South Junction to Mansfield Junction 119.16 - 125.64 St Pancras via Trent
    TSN2 Nottingham London Road to Mansfield Junction 123.23 - 124.22 St Pancras via Corby
TSO Thurso Branch 0.00 - 6.52 Geargemas Junction
TSS Terminus South Curve (Glasgow Central) 0.00 - 0.40 Muirhouse South Junction
TST Sheffield Tram Transfer Line 0.00 - ≈0.27 Tinsley North Junction
TSY Tees Yard 11.69 - 14.03 Darlington
TTA Chinley to Ashburys Line see separate portions
    TTA1 Chinley North Junction to Reddish Junction 168.39 - 181.00 St Pancras via Chaddesden
    TTA2 Reddish Junction to Ashburys 42.77 - 46.24 Liverpool via Cheadle
TTB Treforest Trading Estate Branch 0.00 - 1.22 Treforest Estate Junction Formerly TFT
TTE Tilbury Riverside to Tilbury East Junction Curve 0.16 - 0.40 Tilbury Riverside
TTF Totton to Fawley Branch 82.67 - 92.12 Waterloo
TTG Thirsk Town Branch 0.00 - 1.23 Thirsk Town Junction
TTH Tonbridge to Hastings Line 29.55 - 62.34 Charing Cross via Chelsfield
TUB Turdees Branch 0.00 - 1.34 Turdees Branch Junction Off Salsburgh to Dunsyston Line, serves Blackridge Colliery and Springbank Pit No 7
TUF Tuffley Branch 94.73 - 96.18 + docks Derby
TUN Tunstall Branch 0.00 - 1.08 Longport Junction
TUR Turnchapel Branch/Plymstock Branch 0.00 - 2.21 Turnchapel Branch Junction 0.00 - 1.05 formerly PLS
TVB Tees Valley Branch 0.00 - 7.58 Tees Valley Junction
TVG Tovil Goods Line 0.00 - 0.21 Branch Junction
TVZ Tresavean Branch 310.33 - 313.09 Paddington via Box, Plymouth Millbay (reverse) and Redruth Junction (reverse)
TWE Thornton West to Thornton East Line 0.00 - 0.24 Thornton West Junction
TWM Thornton Junction, Wemyss and Methill Line ?? - ??
TWN Thorpe Le Soken and Walton On The Naze Line 65.20 - 70.17 Liverpool Street
TWS Tilbury Docks West Side Line ?? - ??
TWY Thames Wharf Yard 0.00 - 0.19 Midland Junction
TYB Torksey Branch see separate portions
    TYB1 Clarborough Junction to Cottam CEGB 68.32 - 71.79 Manchester London Road via Woodhead Formerly COT
    TYB2 Cottam to Torksey 71.79 - 73.50 Manchester London Road via Woodhead
    TYB3 Torksey to Sykes Junction 73.50 - 76.46 Manchester London Road via Woodhead
TYC Thoresby Colliery Branch 0.00 - 1.23 Thoresby Colliery Junction
TYL Talyllyn Loop 107.78 - 108.32 Whitchurch Cambrian Junction via Oswestry
TYZ Tycoch Loop 0.03 - 0.24 Mileage change 6ch East of Kidwelly Junction Now in KID1



Introduction | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z | Lines without codes | ELR/LOR converter | LUL system | DLR system | Canals
